Hi-Vol TPU Supply Hose

Description

Most Orders Ship within 8-10 weeks

Hi-Vol TPUTM is an extruded through-the-weave, thermoplastic polyurethane (TPU) fire hose. It provides excellent abrasion resistance, reduced weight, and improved kink resistance in comparison to rubber, along with the benefits of UV and ozone resistance. Its smooth polyurethane finish leads to easier deployment and retrieval, helping you work both faster and smarter.

The Hi-Vol TPU is available in green and orange colors, increasing visibility on the scene. It is the next generation of supply hose, with a compact design that makes it easier to transport and access in high-pressure situations. The Hi-Vol TPU achieves agility without sacrificing water flow capabilities, bringing the best of both worlds to your department.

Downloadable Documents:

Hi-Vol TPU Flyer

10-Year Warranty

Hi-Vol TPU™ Specifications:
Size Pressure Bowl Size Weight (100'/30M) Coil Diameter (100'/30M)
Service Proof Burst
inch mm psi kpa psi kpa psi kpa inch lbs kg inch mm
4 102 200 1,400 400 2,800 600 4,200 4-5/16 75 34.0 22 560
5 127 200 1,400 400 2,800 600 4,200 5-3/8 94 42.6 26 660
6 152 200 1,400 400 2,800 600 4,200 6-15/32 125 56.7 32 813
Technical Data
Outer Thermoplastic Polyurethane
Inner Hose Reinforcement 100% synthetic circular woven
Lengths 25’, 50’, 100’ coupled
Lengths Uncoupled Up to 660’ (201 m)
Factory Installed Couplings Per Customer Requirement
Temperature Range -58º F to 158º F (-50º C to 70º C)

Read more

Hi-Vol TPU Supply Hose

Product form

$946.00

Most Orders Ship within 8-10 weeks Hi-Vol TPUTM is an extruded through-the-weave, thermoplastic polyurethane (TPU) fire hose. It provides excellent abrasion... Read more

SKU: A040-025S5HVTA040ZLB

    Description

    Most Orders Ship within 8-10 weeks

    Hi-Vol TPUTM is an extruded through-the-weave, thermoplastic polyurethane (TPU) fire hose. It provides excellent abrasion resistance, reduced weight, and improved kink resistance in comparison to rubber, along with the benefits of UV and ozone resistance. Its smooth polyurethane finish leads to easier deployment and retrieval, helping you work both faster and smarter.

    The Hi-Vol TPU is available in green and orange colors, increasing visibility on the scene. It is the next generation of supply hose, with a compact design that makes it easier to transport and access in high-pressure situations. The Hi-Vol TPU achieves agility without sacrificing water flow capabilities, bringing the best of both worlds to your department.

    Downloadable Documents:

    Hi-Vol TPU Flyer

    10-Year Warranty

    Hi-Vol TPU™ Specifications:
    Size Pressure Bowl Size Weight (100'/30M) Coil Diameter (100'/30M)
    Service Proof Burst
    inch mm psi kpa psi kpa psi kpa inch lbs kg inch mm
    4 102 200 1,400 400 2,800 600 4,200 4-5/16 75 34.0 22 560
    5 127 200 1,400 400 2,800 600 4,200 5-3/8 94 42.6 26 660
    6 152 200 1,400 400 2,800 600 4,200 6-15/32 125 56.7 32 813
    Technical Data
    Outer Thermoplastic Polyurethane
    Inner Hose Reinforcement 100% synthetic circular woven
    Lengths 25’, 50’, 100’ coupled
    Lengths Uncoupled Up to 660’ (201 m)
    Factory Installed Couplings Per Customer Requirement
    Temperature Range -58º F to 158º F (-50º C to 70º C)

    Read more
